Corbin Russwin - Deadbolts
DL2217 626 Corbin Russwin Locks, Cylinders, Cores, Keyblank
$93.24
Grade 2 Classroom Deadbolt, Conventional Cylinder, Satin Chrome Finish, Non-Handed
In Stock Quantity: 7
Spec Options
Product Info
Technical Specs
Resources
Product Details
Comes in all standard finishes and is non-handed.
- Handing: Non-handed.
- Door Thickness: Standard - 1-3/4" (44mm). Optional door thicknesses available; see Quick Codes.
- Backset: Standard - 2-3/4" (70mm); Optional: 2-3/8" (60mm)
- Front: Standard - brass or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm). Optional: 1" width; see Quick Codes.
- Deadbolt: 1" throw, solid steel deadbolt with hardened, free spinning, steel pin insert.
- Strike: Standard - 2-3/4" (70mm) x1-1/8" (29mm). Optional strikes and wrought boxes available.
- Cylinder: Standard - brass, 6-pin, L4 keyway, 0-bitted. Security cylinder optional; see Quick Codes.
- Keys: Two nickel silver standard.
- Keying Features Available: Master keying; construction master keying; security; visual key control; concealed key control
- Warranty: One-year limited.
Product Specs
BASIC SPECS
ManufacturerCorbin Russwin
SkuDL2217 626
GradeGrade 2
Unit of MeasureEach
Limited Warranty1 Year
Fire Rated3 Hours {A}
FINISH
Finish626/US26D
Finish DescriptionSatin Chrome
Finish FamilyMatte Silver
