ML2048 LSF 626 CL6 Corbin Russwin Locks, Cylinders, Cores, Keyblank

The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt. A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.

• Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
• Door Thickness: 1-3/4" (44mm) standard. Optional door thicknesses available.
• Backset: 2-3/4" (70mm).
• Lockcase: Heavy-gauge steel, 5-7/8" (149mm) x 4" (102mm) x 15/16" (24mm). Optional: non-ferrous lockcase for corrosion resistance.
• Front: Heavy-gauge steel, 8" (203mm) x 1-1/4" (32mm) x -3/32" (2mm). Accommodates flat doors and doors beveled 1/8" (3mm) in 2" (51mm). Furnished 1-1/16" (27mm), optional D138, wide for 1-3/8" (35mm) doors.
• Armored Front: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
• Latchbolt: 2-piece mechanical with anti-friction insert, 5/8" (16mm) x 1" (25mm) x 3/4" (19mm) throw.
• Keys: Two nickel silver standard.
• Federal: Meets FF-H-106C.
• Environmental Product Declaration: (EPD) certified
