DormaKaba - Narrow Stile Mortise Keypad Trim
3020-19-41 DormaKaba Integrated and Pushbutton
$62.29
Drive Assembly, 31/32", LH/LHR
In Stock Quantity: 10
Product Info
Technical Specs
Resources
Product Details
Provides exterior access by combination for narrow stile aluminum glass doors.
- Construction: All metal cast front housing, force-resistant, clutch-protected fixed thumbturn
- Numeric Keypad: Vandal resistant, solid metal pushbuttons
- Locking Device: Adams Rite 4510/4710/4910 mortise latch
- Key Override: Accepts Maximum Security (MS) mortise cylinders; can be used to override the lock combination and gain access using a key. Allows facilities to initiate or maintain a master-keyed security system (keyed alike or keyed differently).
- Latch: Purchased separately (Adams Rite)
- Stile Width: 1⅞" (48 mm) minimum, required for mounting
- Door Thickness: 1¾" (44 mm) maximum
- Strike: Sold separately (Adams Rite or Kaba Ilco Corp.)
- Items Supplied Include: Installation instructions, full-scale template, combination change key, and screwdriver
- Durability: Weather resistant
- Warranty: 1-year warranty
Product Specs
BASIC SPECS
ManufacturerDormaKaba
Sku3020-19-41
Unit of MeasureEach
