LCN - Door Operators
9563IQ-REGSTDDE 92 LH 628 LCN Door Closers and Operator
$6,877.64
Grade 1 Surface Mounted Electromechanical Senior Swing Double Egress Door Operator, 92" Header, Double Lever Arm Regular & Slide Track Arm Standard, Push or Pull Side Mounted, Double Egress, 65" - 98" Door, 90 Deg. Swing, Machine Screws, Satin Aluminum Clear Anodized Finish, Left Handed
Available to Order
Ships in 2 - 3 weeks
Product Info
Technical Specs
Resources
Product Details
The 9560 Senior Swing Series by LCN is an ADA door operator that is a two-in-one swing door operator.
The 9560 Series is a senior Swing operator which means when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic.
- 9560 series operator is shipped with motor gearboxes, control boxes, arms, header, and mounting hardware. Actuators available separately
- Independent pair, surface mounted.
- Meets ADA requirements (power mode only).
- Handed product.
- Pull, Push or Double Egress applications available.
- 72” header length is standard. Specify other length 60” to 98”. Consult factory regarding this option.
- Adjustable hold open period of 1 to 32 seconds in automatic or manual mode.
Product Specs
BASIC SPECS
ManufacturerLCN
Sku9563IQ-REGSTDDE 92 LH 628
GradeGrade 1
InstallationCommercial
OriginUSA
Unit of MeasureEach
Limited Warranty2 Years
FINISH
Finish628/US28
Finish FamilyMatte Silver
