Schlage - Interconnected Locks
CS210-B500BD NEP 619 PLY Schlage Locks, Cylinders, Cores, Keyblank
$361.10
Grade 2 Entrance Single Locking Interconnected Lock, Neptune Lever, Saturn Rose/Plymouth Escutcheon, Not Handed, SFIC Prep Less Core, Square/Full Lip SQ Strike, Satin Nickel Plated Clear Coated
Available to Order
Ships in 6 - 7 weeks
Spec Options
Product Info
Technical Specs
Resources
Product Details
Exceptional performance, aesthetics, and flexibility for both residential and commercial applications.
The CS210 mechanical interconnects provide panic-free, single motion egress and comply with the requirements of the National Fire Protection Association (NFPA) Codes and local building codes. Eighteen lever designs, two outside deadbolt designs and two inside escutcheon designs - each in a choice of seven finishes - ensure the right aesthetics for whatever type of project. The adjustable escutcheon allows each lock to easily support either 4″ or 5-1/2″ door preps, eliminating any job-site surprises.
- 18 lever styles
- Adjustable to 4" and 5-1/2" center-to-center door preparations
- Single motion egress meets Life and Safety code requirements
- Ideal for both new construction and renovation/aftermarket projects
- Easy to install, fits standard door preparations
- Handing reversible
- Two deadbolt designs
- Two escutcheon designs
- Seven finishes
- Suites with F Series and S Series tubular locks
Product Specs
BASIC SPECS
ManufacturerSchlage
SkuCS210-B500BD NEP 619 PLY
GradeGrade 2
InstallationCommercial
Unit of MeasureEach
Fire Rated3 Hours {A}
FINISH
Finish619/US15
