AD200CY50MSKRHO605JLR Schlage Electronics Integrated and Pushbutton

AD Series locks were designed to be adaptable, allowing upgrades to be made without taking the lock off the door.

AD-200 offline locks can be manually programmed, managed by Schlage Express™ or with an offline system from select Software Alliance members.

The AD-200 is available in cylindrical, mortise, mortise deadbolt and exit trim chassis options and features a credential reader, and access control sensors for simplified installation. It is compatible with a wide range of credential options including PIN, magnetic stripe, proximity (125 kHz) and smart (13.56 MHz) credentials; dual authentication card + PIN readers are available for extra security.

AD-200 can work in the same offline system as CO-200, CO-220 and CT5000. They can be manually programmed for basic use or managed with PC-based Schlage Express™ software. Select Software Alliance members also offer access control solutions for the AD-200 with added capability that can include lock schedules and audits. Features and capabilities will vary by system; please visit Software Alliances tab for additional details.

Reader options

• Multi-technology reader compatible with proximity (125 kHz) and Smart (13.56 MHz) card use
• Multi-technology reader with keypad
• Magnetic stripe reader in swipe or insertion styles (triple track, field configurable)
• Magnetic stripe reader with keypad in swipe or insertion styles
• Keypad only

User verification

• Capable of credential verification <1 second
• Up to 5000 users
• Up to 5000 audits

Programming interface

• Schlage Utility Software (SUS) with compatible Android device transfers programming information from computer to lock using the SUS-A cable connection
• Schlage Express PC-based software provides simple access control management for users, audits and locks

Additional

• Battery life - up to 2 years with 4 AA batteries
• Exterior Temp: -31° to 151°F (-35° to 66°C)
• Interior Temp: 32° to 120°F (0° to 49°C) (battery)
• Humidity: 0 - 100% non-condensing

Chassis

• Cylindrical
• Mortise
• Mortise deadbolt
• Exit trim
• Each offered with LED indicator or push button depending on lock function choice

Cylinder and keys

• Standard keyway: Schlage 6-pin Everest 29 S123 with two patented keys
• Classic and restricted keyways, master keying and grand master keying options
• Conventional, FSIC, and SFIC cylinder options
• Less cylinder options made to fit common Sargent®, Corbin Russwin®, Medeco®, Yale® and Falcon® cylinders

Functions

• 70 Classroom/Storeroom (cylindrical and mortise only)
• 50 Office (cylindrical and mortise only)
• 40 Privacy with programmable occupancy indication option
• 60 Apartment
