Von Duprin - Electrified Exit Devices

EL9975L-BE-06 3 26D LHR Von Duprin Exit Device

$3,184.75

Grade 1 Mortise Exit Bar, 36" Device, Passage Function, 06 Lever with Escutcheon Trim, Electric Latch Retraction, Less Dogging, Satin Chrome Finish, Field Reversible

Assembled from stock components. Call for availability.

Product Info
Technical Specs
Resources

Product Details

Devices are ANSI A156.3 – 2001 Grade 1

The 9975 Series is for all types of single or double doors and is UL listed for panic exit hardware.  Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 3 /4" (121mm).

  • Device functions: Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
  • Device lengths: 3' 2'4' to 3' (711mm to 914 mm) Door size 4' 2'10" to 4' (864 mm to 1219 mm) Door size
  • Device centerline from finished floor: 39 13/16" (1011 mm) 39 11/16" (1008 mm) with mullion
  • Center case dimensions: 8" x 2 3/4" x2 3/8" (203mm x 70mm x 60mm)
  • Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
  • Projection: Pushbar neutral – 3 13/16" (97 mm) Pushbar depressed – 3 1/16" (78 mm)
  • Fasteners & sex bolts (SNB): Includes screw pack for 1 3/4" (44mm) and 2 1/4" (57mm) thick metal or wood do

Product Specs

BASIC SPECS
ManufacturerVon Duprin
SkuEL9975L-BE-06 3 26D LHR
GradeGrade 1
InstallationCommercial
OriginUSA
Unit of MeasureEach
Limited Warranty1 Year
Fire RatedNo
FINISH
Finish626/US26D
Finish FamilyMatte Silver
